BEACHTECH 2000
Dimensions
Overall length
5,430 mm
Width
2,500 mm
Height
2,100 mm
Working width
1,850 mm
Weight
Net weight
1,800 kg
Gross weight limit
2,800 kg
Performance data
Max. area coverage
22,200 m²/h
Working depth up to
30 cm
Power Take-Off Shaft Speed
540 rpm (alternatively 1,000 rpm)
Dump height
2,600 mm
Capacity collection hopper
1.5 m³
BEACHTECH 2500
Dimensions
Overall length
6,060 mm
Width
2,500 mm
Height
2,250 mm
Working Width
2,500 mm
Weight
Net weight
2,790 kg
Gross weight limit
4,000 kg
Performance
Max. area coverage
30,000 m²/h
Working depth up to
30 cm
Power Take-Off Shaft Speed
540 rpm
Dump height
2,750 mm
Hopper capacity
2.8 m³
BEACHTECH 3000
Dimensions
Overall length
7,000 mm
Width
2,800 mm
Height
2,250 mm
Working width
2,500 mm
Weight
Net weight
3,200 kg
Gross weight limit
6,200 kg
Performance data
Max. area coverage
30,000 m²
Working Depth up to
30 cm
Power Take-Off Shaft Speed
1,000 rpm
Dump height
1,550 mm
Capacity collecting hopper
0.7 m³
Capacity dump body
4.0 m³
BeachTech Marina
Dimensions
Overall length
5,785 mm
Width
1,770 mm
Height
2,340 mm
Working width
1,400 mm
Weight
Net weight
2,775 kg
Payload
725 kg
Gross weight limit
3,500 kg
Performance
Max. area coverage
15,000 m²/h
Working depth up to
30 cm
Road legal
yes
Capacity collection hopper
0.5 m³
Unloadng height
1,635 mm
Max. working speed (depending on soil conditions)
12 km/h
Engine
Type
Kubota, Turbodiesel
No. of cylinders
4
Power
33,0 kW (42 hp)
Torque
120 Nm @ 2,000 rpm
Displacement
1,498 cm³
Emission standard
EU stage III A; EPA Tier4
BEACHTECH SWEEPY
Dimensions
Overall length
2,550 mm
Width
1,195 mm
Working width
1,050 mm
Height adjustable
from 1,000 to 1,600 mm
Collection hopper
44 l, extractable
Total collection volume
80 l
Performance
Area coverage
max. 4.200 m²/h
Engine
Type
4-stroke gasoline engine with air cooling
Power
7,1 kW (9,6 hp)
Other
Drive
mechanical
Steering system
mechanical - freewheel feature allows for 180 degree turn "on the spot"
Transmission
3 speed forward, 2 speed backward
Cleaning device
with quick-change system, design with
BEACHTECH SWEEPY HYDRO
Dimensions
Overall length
2,650 mm
Width
1,195 mm
Working width
1,050 mm
Height adjustable
from 1,000 mm to 1,600 mm
Collection hopper
44 l, extractable
Total collection volume
80 l
Performance
Area coverage
max. 4.200 m²/h
Engine
No. of cylinders
4
Type
4-stroke gasoline engine with air cooling
Power
7.1 kW (9,6 hp)
Other
Drive
infinitely variable (forward and reverse)
Steering
hydrostatic
Transmission
fully hydrostatic
Cleaning device
with quick change system, design with exchangeable double screens in 2 different mesh sizes
Corrosion
