Dimensions
Overall length
5,430 mm
Width
2,500 mm
Height
2,100 mm
Working width
1,850 mm
Weight
Net weight
1,800 kg
Gross weight limit
2,800 kg
Performance data
Max. area coverage
22,200 m²/h
Working depth up to
30 cm
Power Take-Off Shaft Speed
540 rpm (alternatively 1,000 rpm)
Dump height
2,600 mm
Capacity collection hopper
1.5 m³
Dimensions
Overall length
6,060 mm
Width
2,500 mm
Height
2,250 mm
Working Width
2,500 mm
Weight
Net weight
2,790 kg
Gross weight limit
4,000 kg
Performance
Max. area coverage
30,000 m²/h
Working depth up to
30 cm
Power Take-Off Shaft Speed
540 rpm
Dump height
2,750 mm
Hopper capacity
2.8 m³
Dimensions
Overall length
7,000 mm
Width
2,800 mm
Height
2,250 mm
Working width
2,500 mm
Weight
Net weight
3,200 kg
Gross weight limit
6,200 kg
Performance data
Max. area coverage
30,000 m²
Working Depth up to
30 cm
Power Take-Off Shaft Speed
1,000 rpm
Dump height
1,550 mm
Capacity collecting hopper
0.7 m³
Capacity dump body
4.0 m³
